GSPF Heavy-Duty Clip Spacers for Large-Diameter Bars, 8 to 32 mm
Reinforced polymer clip spacers for large-diameter bars and heavily reinforced elements, with cover up to 100 mm.
- Brand
- GSPF
- Category
- Rebar Spacers & Accessories
- Type
- Individual product
- Reinforced, impact-resistant polymer construction
- Heavy-duty clip for large-diameter steel bars
- Bar diameters from 8 to 32 mm
- Seven cover sizes from 25 to 100 mm
- Larger covers listed for 16 to 32 mm bars
- Packed 250 to 1000 pieces by size
Description
GSPF Heavy-Duty Clip Spacers are clip-on reinforcement spacers for projects where bars are large and loads on the spacer are higher than a standard clip spacer is made for. They are moulded from a reinforced, impact-resistant polymer with a heavier clip and a more rigid geometry.
They are a separate product from the standard Clip Spacers, with their own cover sizes, bar ranges and pack quantities. The two should not be mixed up when specifying.
Key Features and Benefits
Built for large-diameter bars
The heavy-duty clip is made to hold bars from 8 mm up to 32 mm, a range that standard clip spacers do not cover.
Higher-load construction
The reinforced polymer and the more rigid structure are intended to carry higher loads and resist displacement while the reinforcement is placed and the concrete is poured.
Covers up to 100 mm
Cover sizes run from 25 mm to 100 mm, so thicker cover requirements on heavy elements are covered.
Bar range changes with cover
The 25 to 50 mm covers are listed for 8 to 24 mm bars. The 60 to 100 mm covers are listed for 16 to 32 mm bars.
Applications and Use Cases
Heavy-Duty Clip Spacers are used for:
- Infrastructure projects including bridges, tunnels and heavy transportation structures
- Industrial foundations with dense reinforcement
- Large precast components with high load and rigidity requirements
- Heavy civil engineering works
- Reinforced shear walls, beams and slabs with large bar diameters
- Energy, utilities and manufacturing facilities
Technical Specifications
| Product Code | Cover (mm) | Steelbar Dia (mm) | Packing (pcs) |
|---|---|---|---|
| GCSHD25 | 25 | 8-24 | 1000 |
| GCSHD30 | 30 | 8-24 | 1000 |
| GCSHD40 | 40 | 8-24 | 1000 |
| GCSHD50 | 50 | 8-24 | 500 |
| GCSHD60 | 60 | 16-32 | 500 |
| GCSHD75 | 75 | 16-32 | 400 |
| GCSHD100 | 100 | 16-32 | 250 |
Request a quotation
Buy Heavy-Duty Clip Spacers from Global Source Middle East
On heavily reinforced elements, the spacer has to cope with bigger bars and more weight than a standard clip spacer sees. Global Source Middle East supplies GSPF Heavy-Duty Clip Spacers to contractors and precast producers in the UAE. Send the bar diameters, cover and quantities, and we will quote the matching codes.
Frequently Asked Questions
How do Heavy-Duty Clip Spacers differ from the standard Clip Spacers?
They are made for larger bars (8 to 32 mm against 6 to 20 mm) and for higher loads, with covers up to 100 mm. The standard Clip Spacers are a separate product with different cover sizes and bar ranges.
Which bar sizes suit the 100 mm cover?
The 60, 75 and 100 mm covers are listed for 16 to 32 mm bars.
When should I choose the heavy-duty version?
They are built for heavily reinforced elements with larger bars and higher loads than the standard Clip Spacers. Send the bar sizes and cover required, and we will match the product codes.
